Product Description
Get ready for the Fall '26 Electromagnetics course by ordering your premium lab kit today!
This kit has been prepared exclusively by the IEEE student branch for University of South Florida students and contains the components as listed below.
Shipping details and options:
IMPORTANT - all kits ordered by August 28th will be bulk shipped for pick up on campus.
Please enter the following shipping address at checkout:
(Your name here) c/o USF IEEE
4202 East Fowler Ave
ENG030
Tampa, FL 33620
IMPORTANT NOTE: All orders placed before August 28th will be shipped to and must be picked up on campus. Please see the USF IEEE student branch for specific details on picking up your order.
Orders received before August 28th will enjoy discounted bulk shipping cost of $4.99 per kit and will be available to pick up on campus with pick-up some time up to or after Sept. 3rd.
Orders received after August 28th will be sent via two day air express service at a flat rate of $16.97 per kit (kit only) and be sent direct to student address given at checkout.
All kits sales are final once shipped.
FOR REMOTE STUDENTS (NEED KIT SENT OUTSIDE OF USA) - International students (located outside of USA) will be required to pay for additional shipping. The $16.97 fee will be credited towards the preparation of the kit and all customs & shipping documentation for the international shipment from the USA, but does not include the full cost of shipping. Please reach out to us directly at support@eurekaleap.com for assistance and to work out shipping documentation and details. Thank you.
Your custom kit includes:
| Description | Qty/kit | Manufacturer P/N |
| Resistor Carbon Film - 10 Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-10-03 |
| Resistor Carbon Film - 47 Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-47-03 |
| Resistor Carbon Film - 100 Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-100-03 |
| Resistor Carbon Film - 220 Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-220-03 |
| Resistor Carbon Film - 470 Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-470-03 |
| Resistor Carbon Film - 1K Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-1K-03 |
| Resistor Carbon Film - 2.2K Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-2.2K-03 |
| Resistor Carbon Film - 47K Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-47K-03 |
| Resistor Carbon Film - 100K Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-100K-03 |
| Resistor Carbon Film - 470K Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-470K-03 |
| Resistor Carbon Film - 1M Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-1M-03 |
| Resistor Carbon Film - 10M Ohm 1/4W, 5% | 2 | ELRES-CF1/4W-5%-10M-03 |
| Capacitor Mylar Film 0.47uF 100 Volt 5% | 1 | ELCAP-MR-100V-.47U-03 |
| 1uF 50V 10% Multilayer Monolithic Ceramic Capacitor X7R 125C 5mm | 1 | ELCAP-MLC-50V-1U-03 |
| 2.2uF 50V 10% Multilayer Monolithic Ceramic Capacitor X7R 125C 5mm | 1 | ELCAP-MLC-50V-2.2U-03 |
| 4.7uF 50V 20% Multilayer Monolithic Ceramic Capacitor Y5V 85C 5mm | 1 | ELCAP-MLC-50V-4.7U-03 |
| 10uF 50V 10% Multilayer Monolithic Ceramic Capacitor X7R 125C 5mm | 1 | ELCAP-MLC-50V-10U-03 |
| Capacitor Electrolytic Radial 22uF 50V 105C 20% 5x11mm | 1 | ELCAP-AE-50V-22U-03 |
| Capacitor Electrolytic Radial 100uF 50V 105C 20% 8x12mm | 1 | ELCAP-AE-50V-100U-JRB-03 |
| Capacitor Electrolytic Radial 220uF 50V 20% 105C 10x17mm JRB | 1 | ELCAP-AE-50V-220U-03 |
| Capacitor Electrolytic Radial 470uF 50V 20% 105C 13x20mm | 1 | ELCAP-AE-50V-470U-03 |
| Capacitor Electrolytic Radial 1000uF 50V 20% 105C 13x26mm | 1 | ELCAP-AE-50V-1000U-03 |
| Inductor - Power 10mH 10% 85mA Wirewound Leaded Radial | 1 | ELIND-EPWR-10M-10%-01 |
| Inductor - Power 22mH 10% 70mA Wirewound Leaded Radial | 1 | ELIND-EPWR-22M-10%-01 |
| Copper Foil Conductive Tape Double-Sided self-adhesive 2in - 5 inch strip | 1 | ELACC-CT-5x2i-01 |
| 22 AWG Solid Tinned Hook-up Wire Black - 5in lengths | 4 | ELWIRE-HSTC-22AWG-BK-5i-01 |
| 22 AWG Solid Magnetic Wire - 15in lengths | 2 | ELWIRE-MEC-22AWG-15i-01 |
| Sandpaper Sheet Small 1inx1in 120-grit Emery cloth aluminum oxide | 4 | ELACC-SP-120G-1x1i-01 |
| Binder Clips Large (2in) Black | 2 | ELACC-BC-LG2i-01 |
| Rubber Band Thin Size 19 (3 1/2 x 1/16 in) Tan | 4 | ELACC-RB-S19-1-01 |
| Uncoated 77 Ferrite Core ROD Type 1.625" (41.28mm) Length Width 0.374" (9.50mm) Diameter Height | 1 | ELACC-FR-.374x1.625-01 |
| 830pt Breadboard w/two power rails & adhesive backing by Busboard | 1 | BBP-10010-EH |
| Jumper Wire set - 140 pcs., 22AWG, pre-formed, 14 lengths, 9 colors | 1 | WIR-020-01420-EH |
| 1Gallon Zipper Plastic Storage Bag Clear | 1 | ELACC-PRB-1G-1-01 |
