Product Description
The MEGA NANO CH-340-01 is a compact and versatile microcontroller board designed for a wide range of electronics projects. It combines the power of the ATmega2560 microcontroller with the compact size of a Nano board, making it an excellent choice for projects that require both high performance and a small footprint. The board features the CH340 USB-to-serial converter, providing reliable USB connectivity for programming and communication.
Key features of the MEGA NANO CH-340-01 include:
- Microcontroller: ATmega2560
- Operating Voltage: 5V
- Input Voltage (recommended): 7-12V
- Digital I/O Pins: 54 (of which 15 can be used as PWM outputs)
- Analog Input Pins: 16
- DC Current per I/O Pin: 20 mA
- Flash Memory: 256 KB (ATmega2560) of which 8 KB used by the bootloader
- SRAM: 8 KB (ATmega2560)
- EEPROM: 4 KB (ATmega2560)
- Clock Speed: 16 MHz
- USB-to-Serial Converter: CH340
- Form Factor: Nano-compatible
Additional features:
- Compact Size: Ideal for projects with limited space
- USB Connection: Easy programming and communication via USB
- Onboard LED: Built-in LED for basic testing and debugging
- Compatibility: Works with the Arduino IDE, making it easy to program and integrate with existing projects
- Versatility: Suitable for a wide range of applications, from simple DIY projects to more complex designs
Applications:
- Prototyping and Development: Great for testing and developing new ideas
- Embedded Systems: Suitable for integration into custom electronic devices
- Robotics: Ideal for controlling motors, sensors, and other components
- IoT Projects: Perfect for creating Internet of Things devices
The MEGA NANO CH-340-01 offers the power and flexibility of the ATmega2560 in a compact, Nano-sized board. Its combination of high performance, small size, and affordability makes it a popular choice for hobbyists, students, and professionals alike.
